320 Channel 5 Chute Optical Rice Color Sorter Machine for Pistachio Cashews Walnuts Almonds Nut

Fully enclosed mechanical structure, more stable and reliable. Heat dissipation device is introduced to improve the life and stability of the machine. Adopt advanced electronic system to ensure stable working efficiency.

Model

6-6SXZ-320

Color

White

Output(T/H)

2-6

Sorting Material

Rice,Pistachio,Cashews,Walnuts,Almonds,Nut,Grain

Type

Chute

Channel/Chute/Width

320 Channel / 5 Chute

About this iteam

Sorting Accuracy:99.99%,Rejection Rate:≥12：1，Weight:900KG, Power:2.9KW, Air Pressure:0.6-0.8Mpa, Air Consumption:1300-2800L/min

Categorie:

Multifunction color sorter

E-mail:

wycolorsorter@163.com

Send Inquiry

hiddenValue

Introduction
Parameters
Sorting Material
Working principle

Performance feature

●Focus on systematic and original design

●Multi - dimensional intelligent color sorting

●Intelligent and convenient interactive interface

●Make color sorting more professional and intelligent

1、According to the characteristics of rice, a high-quality special industrial camera is made to ensure that every grain of rice can be perfectly photographed in the image sensor.

2、Special anodic oxidation treatment technology is adopted to make the surface of the slide more smooth, more durable, longer service life and more stable performance.

3、Fully enclosed mechanical structure, more stable and reliable. Heat dissipation device is introduced to improve the life and stability of the machine. Adopt advanced electronic system to ensure stable working efficiency.

4、Advanced optical system design, effective identification of small particles such as disease spots, pale yellow water, needle-tip blackheads, etc.

5、Accurate automatic calibration system and humanized man-machine interface make the operation of color sorter more convenient.

model	Output(T/H)	Sorting Accuracy(%)	Rejection Rate	Weight/(Kg)	Whole Power (KW)	Dimensions (LxWxH)mm	Air Pressure (Mpa)	Air Consumption (L/min)	Voltage
6-SXM-32	0.2-0.5	≥99.99	≥30:1	180	0.5	5009001520	0.6-0.8	100-300	220V/50Hz
6-SXM-64	0.3-0.7	≥99.99	≥30:1	280	0.75	78015271543	0.6-0.8	200-600	220V/50Hz
6-SXM-128	1-6	≥99.99	≥30:1	450	1.1	125015351832	0.6-0.8	600-1200	220V/50Hz
6-SXM-192	2-9	≥99.99	≥30:1	600	1.6	162015351832	0.6-0.8	800-1800	220V/50Hz
6-SXM-256	2.6-12	≥99.99	≥30:1	750	2.3	185515401852	0.6-0.8	1000-2400	220V/50Hz
6-SXM-320	3-15	≥99.99	≥30:1	900	2.9	224415401852	0.6-0.8	1300-2800	220V/50Hz
6-SXM-384	5-17	≥99.99	≥30:1	1100	3.1	259515401852	0.6-0.8	1500-3200	220V/50Hz
6-SXM-448	5-17	≥99.99	≥30:1	1350	3.9	290515401852	0.6-0.8	1800-3800	220V/50Hz
6-SXM-512	7-27	≥99.99	≥30:1	1500	5	302515401852	0.6-0.8	2000-4000	220V/50Hz
6-SXM-640	9-35	≥99.99	≥30:1	1800	6.5	375015401852	0.6-0.8	2600-5000	220V/50Hz
6-SXM-768	11-39	≥99.99	≥30:1	2100	7.0	443015401852	0.6-0.8	3000-6000	220V/50Hz

The above parameters take japonica rice (3%) as an example, and the specific indicators vary depending on the impurity content.

Examples of color sorting

Analyze every detail and select every raw material.

A number of patent technology innovation, high quality implementation, intelligent sorting industry new height!
Working principle

Focus on the field of color sorting and lead the industry standards;

Create unlimited space, sorting to improve quality.
