Chute Type Color Sorter

Apply to sorting: rice,wheat,corn,bean,soybean,bean,sesame,glass..... Advantage: High cost performance, suitable for small particle materials, wider application range，easy maintenance and low maintenance cost

Color

White

Output(T/H)

0.6-2.5

Sorting Material

Grain,Wheat,Corn,Seed,Peanut,Coffee Bean

Type

Chute

Channel/Chute/Width

128 Channel / 2 Chute

About this iteam

Sorting Accuracy:99.99% ，Rejection Rate:≥12：1, Weight:450KG, Power:1.1KW, Air Pressure:0.6-0.8(Mpa) Air Consumption：600-1200（L/Min)

Categorie:

Home

E-mail:

wycolorsorter@163.com

Send Inquiry

hiddenValue

Introduction
Parameters
Sorting Material
Working principle

Performance feature

●CCD core intelligent sensor

●Original intelligent image processing algorithm

●Brainlike thinking intelligent embedded chip

●Fast and accurate color sorting solution

1、With high sensitivity and high resolution industrial color CCD sensor, it can instantly capture tiny defects with an accuracy of 0.04 square millimeters.

2、The world's leading color selection machine special injection valve, long life, fast response speed, good consistency and other advantages.

3、Adopt the latest FPGA processing technology to analyze and process the signal characteristics of the selected materials and identify tiny particles of 0.04 square mm.

4、Adopt high speed air valve with high response frequency,low powerconsumption and long service life.

5、The main control system adopts high-end embedded processing chip toeffectively improve the color sorting accuracy.

6、Automatic fault alarm system, modular structure, easy to maintain.

model	Output(T/H)	Sorting Accuracy(%)	Rejection Rate	Weight/(Kg)	Whole Power (KW)	Dimensions (LxWxH)mm	Air Pressure (Mpa)	Air Consumption (L/min)	Voltage
6-6SXZ-32	0.2-0.5	≥99.9	≥12:1	180	0.5	5009001520	0.6-0.8	100-300	220V/50Hz
6-6SXZ-64	0.3-0.9	≥99.9	≥12:1	280	0.75	78015271543	0.6-0.8	200-600	220V/50Hz
6-6SXZ-128	0.6-2.5	≥99.9	≥12:1	450	1.1	125015351832	0.6-0.8	600-1200	220V/50Hz
6-6SXZ-192	1-4	≥99.9	≥12:1	600	1.6	162015351832	0.6-0.8	800-1800	220V/50Hz
6-6SXZ-256	1.4-5	≥99.9	≥12:1	750	2.3	185515401852	0.6-0.8	1000-2400	220V/50Hz
6-6SXZ-320	2-6	≥99.9	≥12:1	900	2.9	224415401852	0.6-0.8	1300-2800	220V/50Hz
6-6SXZ-384	2.5-8	≥99.9	≥12:1	1100	3.1	259515401852	0.6-0.8	1500-3200	220V/50Hz
6-6SXZ-448	3-10	≥99.9	≥12:1	1350	3.9	290515401852	0.6-0.8	1800-3800	220V/50Hz
6-6SXZ-512	3.5-12	≥99.9	≥12:1	1500	5	302515401852	0.6-0.8	2000-4000	220V/50Hz
6-6SXZ-640	4.5-16	≥99.9	≥12:1	1800	6.5	375015401852	0.6-0.8	2600-5000	220V/50Hz
6-6SXZ-768	5.5-20	≥99.9	≥12:1	2100	7.0	443015401852	0.6-0.8	3000-6000	220V/50Hz
